    2200rpm Front End Wheel Loader Cummins Engine Water Cooling Fast Operation

    Ask Lasest Price
    Brand Name : WEA
    Model Number : W138
    Price : usd24000/unit-usd29000/unit
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 500 units per year
    Delivery Time : 35 working days
    • Product Details
    • Company Profile

    2200rpm Front End Wheel Loader Cummins Engine Water Cooling Fast Operation

    China Construction Machinery Wheeled Front End Loader With 92kw Weichai Engine
    Product Description
    China Construction Machinery Wheeled Front End Loader With 92kw Weichai Engine

    MAIN FEATURES


    1. Wheel Loader is a kind of earthwork construction machinery widely usedd in highway, railway, construction, port, mine and other construction projects.

    2. It is mainly used for shoveling bulk materials such as soil, sand, lime, coal, etc. It can also be used for slight shoveling and excavation of ores, hard soil, etc.

    3. Different auxiliary working devices can also be used for bulldozing, lifting and loading and unloading of other materials such as wood.


    ADVANTAGES

    1. Fast operation and high efficiency

    2. Good maneuverability

    3. Simple and portable operation

    TECHNICAL PAREMETERS

    Operating weight10200kgSystem pressure16MPa
    Rated Bucket Capacity1.8m3/2.2m3Flow rate at engine rated speed220L/min
    Max. breakout force96kNLifting cylinder2-125x697mm
    Dumping clearance2934mmTilting cylinder1-150x434mm
    Dumping reach1043mmLifting time5.2s
    Tipping load full turn5880kgLowering time3.0s
    Max. drawing force96kNDumping time1.1s
    Gear ratio of main drive4.222Traveling speedI II III IV
    Gear ratio of hub reduction4.8Forward7.8 14.7 23.5 41.2
    Max. gradient ability30°Reverse10.8 31.6
    31.6Streering angle±38°Fuel tank130L
    Min. steering radius4885mmT/C and T/M38L
    System pressure16MPaHydraulic tank120L
    Flow rate at engine rated speed100ml/minF/R axles15L/15L
    No, of cylinders-BorexStroke2-70x357mmTyre size17.5-25-12PR

    PRODUCT DETAILS

    SHIPMENT
    MORE DETAILS ABOUT US
    FAQ
    1. Are you manufacturer?
    Yes, we are a manufacturer located in jiangsu porvince which is in the manufacturing center of construction machinery.
    2. What kind terms of payment can be accepted?
    Normally we can work on T/T or L/C term.
    3. What about the delivery time?
    7-30 days after receiving the deposit.
    4. what about the warranty time?
    12 months after shipment or 2000 working hours
